With so many multimeters on the market, choosing the best unit for your electrical troubleshooting is vital. Fluke is one of the top brands on the market with exceptional digital multimeters on offer. Today, we will take a look at the Fluke 174 digital multimeter. Read this Fluke 174 review to the end to find out more about its features, functions, pros, and cons.
The Fluke 174 True-RMS multimeter is a durable and reliable tool that performs a wide range of functions. It can read up to 1000V AC/DC, making it great for both basic and professional use. It also offers accurate and fast results as it is a True-RMS device.
Technical Specification of the Fluke 174 True RMS Multimeter
|Storage Temperature:||-30°C to +60°C|
|Operating Temperature:||-10°C to +50°C|
|Humidity (without condensation):||0% – 90% (0°C – 35°C)
0% – 70% (35°C – 50°C)
|Overvoltage Category:||EN 61010–1 to 1000 V CAT III
EN 61010–1 to 600 V CAT IV
|DC Volts:||Accuracy: ±(0.15% + 2)
Max. Resolution: 0.1 mV
Maximum: 1000 V
|AC Volts:||Accuracy: ±(1.0% + 3)
Max. Resolution: 0.1 mV
Maximum: 1000 V
|Current DC:||Accuracy: ±(1.0% + 3)
Max. Resolution: 0.01 mA
Maximum: 10 A
|Current AC:||Accuracy: ±(1.5% + 3)
Max. Resolution: 0.01 mA
Maximum: 10 A
|Resistance:||Accuracy: ±(0.9% + 1)
Max. Resolution: 0.1 Ω
Maximum: 50 MΩ
|Capacitance:||Accuracy: ±(1.2% + 2)
Max. Resolution: 1 nF
Maximum: 10,000 µF
|Frequency:||Accuracy: ±(0.1% + 1)
Max. Resolution: 0.01 Hz
Maximum: 100 kHz
|Battery life:||Alkaline ~200 hours typical, without backlight|
|Price:||Check Today’s Price|
This multimeter is also safe to use as it has CAT IV 600V/ CAT III 1000V safety rating. So, this is a device that you will use for many years to come. Due to its ease of use and reliability, the Fluke 174 multimeter allows the user to find issues very quickly and can be utilized to measure voltage, current, capacitance, frequency, and much more.
Summary of Contents
- 1 Technical Specification of the Fluke 174 True RMS Multimeter
- 2 True RMS Fluke 174 Review
- 3 What we liked about the Fluke 174 multimeter
- 4 What we didn’t like about the Fluke 174 true rms multimeter
- 5 Who is this unit best suited for?
- 6 FAQ
True RMS Fluke 174 Review
Similar to many other Fluke multimeters, the Fluke 174 is also sturdily made with durable plastic. This means that it will stand the test of time and won’t crash easily while in use. Also, this gadget is safety rated to CAT IV 600V/ CAT III 1000V. This means that it can withstand high AC/DC voltages of up to 1000V. This is great for such an affordable and compact unit.
The dial selector is also easy to use and you don’t need any knowledge to adjust it. But if you’re not sure about how to use the meter, a user manual is included to direct you. After use, you can safely keep the gadget in the ergonomic and robust carrying case with a protective holster.
The screen that the Fluke 174 has is not only large but also very clear. This makes the reading of results easy as it is also bright. With the backlit function, you will not have issues reading results in tight places without proper lighting. As a busy electrician or technician who works in tricky conditions, then you will find this device a good choice for your job.
This is the perfect tool for busy electricians. Instead of carrying different tools to perform a wide range of functions, the Fluke offers many functions in one device. Some of the tests that it performs include resistance, current, continuity, capacitance, diodes, and voltage.
Furthermore, this tool is very powerful as it runs on 3 AAA batteries. This is enough power to run the device for several hours considering other units feature only 2 AA batteries.
The True-RMS feature makes the Fluke 174 multimeter to be ideal for professional use. This is because it can provide accurate results even on non-linear signals. One of the important steps in repairing or maintaining electrical systems is having a unit that offers precise and fast results. With the Fluke 174 DMM, you can fully depend on it even for your HVAC systems.
Auto-hold and Auto-ranging
Other exceptional features of this device are the auto-hold and auto-ranging features. The automatic hold feature enables the user to pause or put on hold their results and record them at a later stage. So, if you’re busy or are working on different projects at the same time, you can put this unit on hold and continue using it later without erasing the test results.
Also, the auto-ranging feature is vital as it allows you to either select the manual or auto-ranging function.
Intuitive user interface
Since electricians usually work in tight areas, you need to pick a meter that can fit easily and is not difficult to handle. The Fluke 174 DMM is well designed for ease of use. All the buttons and ports on the device are properly designed for easy use. They are also well-labeled thus it is difficult to confuse probes or even test leads.
This is a versatile unit but it is offered at a very great price. When compared to other multimeters, this digital device is slightly affordable as it costs less but features more functions and attributes. It is also compact and sturdy with a storage case.
If you decide to invest in a quality multimeter, it is only wise that you also acquire a device with a warranty. Some brands do not offer a warranty and this can turn out to be challenging. Fluke offers warranties on its products and the Fluke 174 comes with a limited lifetime warranty.
Check Today’s Price
What we liked about the Fluke 174 multimeter
- Durably made for longevity
- Backlit display allows users to take tests in all conditions
- It has a safety rating of up to 1000V CAT III
- Performs several functions
- Simple to use
- Delivers fast and accurate results
- Large display for offering clear results
- Lifetime warranty
What we didn’t like about the Fluke 174 true rms multimeter
- Some users will find it a bit costly
- A number of users have complained that the screen is big but the display area is very small
Who is this unit best suited for?
There is no doubt that the Fluke 174 multimeter is a sturdy and reliable device that will serve the user for several years to come. Also, it comes with lots of amazing features that are great for starters as well as beginners. Overall, this is a nice tool for newbies and electrician enthusiasts. This is because it lacks some vital features that are needed in high-end units. But it can still be used by professional technicians and HVAC electricians as it is a True-RMS multimeter.
The Fluke 174 digital multimeter is simple to use the device. It is also sold at a favorable price but offers some amazing features. This is a durable and reliable unit that will serve users even in the toughest of conditions. The sturdy plastic construction and durable carrying case ensure that this device survives droppings and is kept well. With an IP54 rating, this is a really durable unit that will troubleshoot a wide range of electrical problems.
Question: What should I consider when picking a Fluke Multimeter?
Answer: Choosing a multimeter for the first time is not easy. This is because you have to consider several factors in order to land the best device for your job. Some multimeters are great for starters while others are ideal for professionals. Some of the things to consider include what the multimeter does, it’s accuracy, construction, display, ease of use, safety, connections, and the overall value of the meter.
Ensure to pick a robust unit that is also very reliable in performance. Most of the latest and advanced units come with a wireless connection through Bluetooth or Wi-Fi.
Question: If I test a circuit with more than 400ma, will it blow the fuse?
Answer: Yes, it will. When picking a multimeter, make sure that you check what its maximum capacity is for voltage, current, capacitance, resistance, temperature, and frequency. Different digital multimeters have different capacities. In this case, testing a circuit that is more than 400ma will cause the fuse to blow. So, you should ensure that you test circuits that are less than 400ma.
Still, have a question after reading this Fluke 174 Review article? Comment below.
